BGS GeoSure: Landslides

BGS Datasets

Key information

Scale:
1:50 000
Coverage:
Great Britain
Availability:
Licensed
Format:
GIS polygon data (ESRI, MapInfo, others available by request)
Price:

£0.3 per km2. Subject to number of users, licence fee and data preparation fee.

Uses:
Local-level use

Get data

Free access

Our free data is available under the Open Government Licence. Please acknowledge reproduced BGS materials.

Sample mapsiGeology app (iOS)
Supporting documents

Landslides occur ultimately due to the effect of gravity, although other factors such as geology, topography, weathering, drainage and man-made construction can all contribute to the overall stability of a slope.

Landslides are commonly divided into four categories: falls, topples, slides or flows.

Landslides rarely comprise a single type of movement but are often the result of a combination of several types.

Whilst BGS currently has over 17 000 landslides in its National Landslide Database many of these are ancient and occurred under different climatic conditions to those of the present day (e.g. Pleistocene). If left undisturbed these ancient mass movement deposits may remain stable for many years, however poorly planned development can sometimes reactivate these ancient slides.

Downslope movement of materials through landsliding may damage buildings or infrastructure through loss of support or due to direct impact.

Common causes of damage due to landslide relate to:

  • removal of ground that is supporting a property
  • stretching or compression of a building as the ground moves
  • material falling onto the property from above
  • material flowing into the property from upslope

The potential for landsliding (slope instability) to be a hazard has been assessed using 1:50 000 scale digital maps of superficial and bedrock deposits. These have been combined with information from the BGS National Landslide Database and scientific and engineering reports.

The detailed digital data illustrated in the map are available as attributed vector polygons, as raster grids and in spreadsheet format.

More information about the landslide data products

BGS currently has three datasets providing information on landslides in Great Britain. These products differ in both their collection method and also their intended use.

National Landslide Database

The BGS National Landslide Database currently documents over 17 000 landslides across Great Britain. The database was an inherited dataset, based on a search of secondary sources conducted for the Department of the Environment (DoE) in the 1980s and 1990s.

Since the foundation of the DoE data set BGS has continued to populate this database.

The purpose of this database is to provide a detailed record of landslide events across Great Britain. The database contains over 35 fields which can be attributed with information on the type of landslide, age and causes.

BGS Geology mass movement layer

The BGS Geology mass movement layer displays mapped landslides that have been recorded by field geologists. The mass movement layer does not distinguish between different types of failures; it is purely an outline of the landslide deposit.

BGS GeoSure

BGS GeoSure is a national dataset that assesses the potential for ground movement and subsidence across Great Britain. It contains six layers, one of which is for landslides.

BGS GeoSure takes into account the local geology and slope of an area along with the geotechnical and structural characteristics of a geological formation. These conditioning factors are combined within GIS and the result is a susceptibility map of the UK. The BGS GeoSure assessment does not show risk or seek to determine the temporal distribution of landsliding.

Get in touch

For more information about our datasets, technologies and map viewers please contact us
